Claude AI

Custom Ocean integration

This integration was created using the custom Ocean integration builder.
Please note that:

  1. This integration will not be listed in the Data sources page of your Port application, and must be installed manually using the instructions on this page.
  2. This integration will not create components (e.g. blueprints, mapping, etc.) in your portal automatically, you will need to create them manually using the instructions on this page.

Port's Claude AI integration allows you to ingest Claude API usage metrics into your software catalog using the Ocean Custom Integration framework. After installing the integration, you can create dashboards to monitor API usage, track costs, analyze model performance, and measure workspace-level metrics using Port's dashboard widgets.

Supported metrics​

The Claude AI integration can ingest usage metrics from the Anthropic Admin API into Port. The Admin API provides two distinct types of usage tracking:

Claude API usage (programmatic)​

These endpoints track usage from programmatic API calls made with API keys:

  • claude_usage_record - Daily usage metrics from /v1/organizations/usage_report/messages including token consumption (uncached input, output, cache read, cache creation) and web search requests.
  • claude_cost_record - Cost tracking from /v1/organizations/cost_report for monitoring organizational spending.
  • claude_workspace_usage - Usage metrics grouped by workspace_id.
  • claude_model_usage - Usage metrics grouped by model.

Claude Code usage (CLI/IDE)​

This endpoint tracks usage from the Claude Code CLI and IDE extensions:

  • claude_code_analytics - Claude Code usage metrics from /v1/organizations/usage_report/claude_code including sessions, lines of code added/removed, commits, pull requests, tool actions, and per-actor breakdowns.
Important distinctions
  • API usage tracks programmatic calls made via API keys (e.g., applications calling the Messages API).
  • Claude Code usage tracks developer activity through the Claude Code CLI or IDE extensions.
  • Web console usage (Claude.ai) is included in API usage metrics.
  • The Anthropic Admin API does not provide request counts (success/failure) - only token consumption metrics are available.

Prerequisites​

To use this integration, you need:

  • An Anthropic Admin API key generated from the Admin section of the Anthropic Console.
  • The API key should have permissions to read usage data and billing information.

API limitations​

The Anthropic Admin API has the following constraints that affect how you configure the integration:

ConstraintDetails
starting_at requiredAll usage and cost endpoints require a starting_at date parameter.
Daily bucket limitWhen using bucket_width=1d, the maximum limit is 31 days per request.
Date formatMessages and cost endpoints use RFC 3339 format (2026-01-01T00:00:00Z). Claude Code endpoint uses YYYY-MM-DD format.
PaginationLarge datasets require handling has_more and next_page tokens for complete data retrieval.
No request countsThe API does not provide request success/failure counts - only token consumption metrics.
No organization infoUsage responses do not include organization_id or organization_name fields.
Grouping fieldsFields like workspace_id, model, api_key_id are only populated when using corresponding group_by[] parameters.

Installation​

Choose one of the following installation methods to deploy the Ocean Custom Integration:

Prerequisites

To install the integration, you need a Kubernetes cluster that the integration's container chart will be deployed to.

Please make sure that you have kubectl and helm installed on your machine, and that your kubectl CLI is connected to the Kubernetes cluster where you plan to install the integration.

Troubleshooting

If you are having trouble installing this integration, please refer to these troubleshooting steps.

Installation

  1. Add Port's Helm repo and install the Ocean Custom Integration:
Replace placeholders

Remember to replace the placeholders for YOUR_PORT_CLIENT_ID, YOUR_PORT_CLIENT_SECRET, and YOUR_ANTHROPIC_ADMIN_API_KEY.

helm repo add --force-update port-labs https://port-labs.github.io/helm-charts
helm upgrade --install my-ocean-claude-integration port-labs/port-ocean \
  --set port.clientId="YOUR_PORT_CLIENT_ID" \
  --set port.clientSecret="YOUR_PORT_CLIENT_SECRET" \
  --set port.baseUrl="https://api.getport.io" \
  --set initializePortResources=true \
  --set scheduledResyncInterval=120 \
  --set integration.identifier="my-ocean-claude-integration" \
  --set integration.type="custom" \
  --set integration.eventListener.type="POLLING" \
  --set integration.config.baseUrl="https://api.anthropic.com" \
  --set integration.config.authType="api_key" \
  --set integration.config.apiKeyHeader="x-api-key" \
  --set integration.secrets.apiKey="YOUR_ANTHROPIC_ADMIN_API_KEY"
Selecting a Port API URL by account region

The port_region, port.baseUrl, portBaseUrl, port_base_url and OCEAN__PORT__BASE_URL parameters are used to select which instance of Port API will be used.

Port exposes two API instances, one for the EU region of Port, and one for the US region of Port.

Configuration parameters

This table summarizes the available parameters for the installation.

ParameterDescriptionExampleRequired
port.clientIdYour Port client id.✅
port.clientSecretYour Port client secret.✅
port.baseUrlYour Port API URL - https://api.getport.io for EU, https://api.us.getport.io for US.✅
integration.config.baseUrlThe base URL of the Anthropic API.https://api.anthropic.com✅
integration.config.authTypeThe authentication type for the API (use api_key for Anthropic).api_key✅
integration.config.apiKeyHeaderThe header name for the API key authentication.x-api-key✅
integration.secrets.apiKeyYour Anthropic Admin API key from the Anthropic Console.sk-ant-admin01-...✅
integration.eventListener.typeThe event listener type. Read more about event listeners.POLLING✅
integration.typeThe integration type (must be custom for Ocean Custom Integration).custom✅
integration.identifierUnique identifier for the integration instance.my-ocean-claude-integration✅
scheduledResyncIntervalThe number of minutes between each resync. When not set the integration will resync for each event listener resync event. Read more about scheduledResyncInterval.120❌
initializePortResourcesDefault true. When set to true the integration will create default blueprints and the port App config Mapping.true❌
sendRawDataExamplesEnable sending raw data examples from the third party API to Port for testing and managing the integration mapping. Default is true.true❌

Advanced integration configuration

For advanced configuration such as proxies or self-signed certificates, click here.

All Ocean integrations expose a health check endpoint at /docs that you can use to verify the integration is running and access its API documentation.

Set up data model​

Before the integration can sync data, you need to create the required blueprints in Port. These blueprints define the data model for your Claude metrics.

To create the blueprints:

  1. Go to your Builder page.

  2. Click on the + Blueprint button.

  3. Copy and paste each blueprint JSON from the sections below.

    Claude AI usage record blueprint (click to expand)

    Daily usage metrics from the Messages API:

    {
      "identifier": "claude_usage_record",
      "description": "Daily Claude AI API usage metrics",
      "title": "Claude AI Usage Record",
      "icon": "Claude",
      "schema": {
        "properties": {
          "record_date": {
            "type": "string",
            "format": "date-time",
            "title": "Record Date (UTC)"
          },
          "uncached_input_tokens": {
            "type": "number",
            "title": "Uncached Input Tokens"
          },
          "output_tokens": {
            "type": "number",
            "title": "Output Tokens"
          },
          "cache_read_input_tokens": {
            "type": "number",
            "title": "Cache Read Input Tokens"
          },
          "cache_creation_5m_tokens": {
            "type": "number",
            "title": "Cache Creation (5min) Tokens"
          },
          "cache_creation_1h_tokens": {
            "type": "number",
            "title": "Cache Creation (1hr) Tokens"
          },
          "web_search_requests": {
            "type": "number",
            "title": "Web Search Requests"
          }
        },
        "required": ["record_date"]
      },
      "mirrorProperties": {},
      "calculationProperties": {
        "total_input_tokens": {
          "title": "Total Input Tokens",
          "description": "Sum of uncached input and cache read tokens",
          "calculation": ".properties.uncached_input_tokens + .properties.cache_read_input_tokens",
          "type": "number"
        },
        "total_tokens": {
          "title": "Total Tokens",
          "description": "Sum of all input and output tokens",
          "calculation": ".properties.uncached_input_tokens + .properties.cache_read_input_tokens + .properties.output_tokens",
          "type": "number"
        }
      },
      "aggregationProperties": {},
      "relations": {}
    }
    Claude AI cost record blueprint (click to expand)

    Cost tracking for organizational spending:

    {
      "identifier": "claude_cost_record",
      "description": "Daily cost tracking for Claude API usage",
      "title": "Claude AI Cost Record",
      "icon": "Claude",
      "schema": {
        "properties": {
          "record_date": {
            "type": "string",
            "format": "date-time",
            "title": "Record Date (UTC)"
          },
          "amount": {
            "type": "number",
            "title": "Cost Amount"
          },
          "currency": {
            "type": "string",
            "title": "Currency"
          }
        },
        "required": ["record_date"]
      },
      "mirrorProperties": {},
      "calculationProperties": {},
      "aggregationProperties": {},
      "relations": {}
    }
    Claude AI workspace usage blueprint (click to expand)

    Usage metrics grouped by workspace:

    {
      "identifier": "claude_workspace_usage",
      "description": "Usage metrics broken down by workspace",
      "title": "Claude AI Workspace Usage",
      "icon": "Claude",
      "schema": {
        "properties": {
          "record_date": {
            "type": "string",
            "format": "date-time",
            "title": "Record Date (UTC)"
          },
          "workspace_id": {
            "type": "string",
            "title": "Workspace ID"
          },
          "uncached_input_tokens": {
            "type": "number",
            "title": "Uncached Input Tokens"
          },
          "output_tokens": {
            "type": "number",
            "title": "Output Tokens"
          },
          "cache_read_input_tokens": {
            "type": "number",
            "title": "Cache Read Input Tokens"
          },
          "cache_creation_5m_tokens": {
            "type": "number",
            "title": "Cache Creation (5min) Tokens"
          },
          "cache_creation_1h_tokens": {
            "type": "number",
            "title": "Cache Creation (1hr) Tokens"
          },
          "web_search_requests": {
            "type": "number",
            "title": "Web Search Requests"
          }
        },
        "required": ["record_date", "workspace_id"]
      },
      "mirrorProperties": {},
      "calculationProperties": {
        "total_tokens": {
          "title": "Total Tokens",
          "calculation": ".properties.uncached_input_tokens + .properties.cache_read_input_tokens + .properties.output_tokens",
          "type": "number"
        }
      },
      "aggregationProperties": {},
      "relations": {}
    }
    Claude AI model usage blueprint (click to expand)

    Usage metrics grouped by model:

    {
      "identifier": "claude_model_usage",
      "description": "Usage metrics broken down by Claude model type",
      "title": "Claude AI Model Usage",
      "icon": "Claude",
      "schema": {
        "properties": {
          "record_date": {
            "type": "string",
            "format": "date-time",
            "title": "Record Date (UTC)"
          },
          "model": {
            "type": "string",
            "title": "Model"
          },
          "uncached_input_tokens": {
            "type": "number",
            "title": "Uncached Input Tokens"
          },
          "output_tokens": {
            "type": "number",
            "title": "Output Tokens"
          },
          "cache_read_input_tokens": {
            "type": "number",
            "title": "Cache Read Input Tokens"
          },
          "cache_creation_5m_tokens": {
            "type": "number",
            "title": "Cache Creation (5min) Tokens"
          },
          "cache_creation_1h_tokens": {
            "type": "number",
            "title": "Cache Creation (1hr) Tokens"
          },
          "web_search_requests": {
            "type": "number",
            "title": "Web Search Requests"
          }
        },
        "required": ["record_date", "model"]
      },
      "mirrorProperties": {},
      "calculationProperties": {
        "total_tokens": {
          "title": "Total Tokens",
          "calculation": ".properties.uncached_input_tokens + .properties.cache_read_input_tokens + .properties.output_tokens",
          "type": "number"
        }
      },
      "aggregationProperties": {},
      "relations": {}
    }
    Claude Code analytics blueprint (click to expand)

    Claude Code usage metrics for tracking development activity:

    {
      "identifier": "claude_code_analytics",
      "description": "Daily Claude Code usage metrics including sessions, lines of code, commits, and PRs",
      "title": "Claude Code Analytics",
      "icon": "Claude",
      "schema": {
        "properties": {
          "record_date": {
            "type": "string",
            "format": "date-time",
            "title": "Record Date (UTC)"
          },
          "organization_id": {
            "type": "string",
            "title": "Organization ID"
          },
          "actor_type": {
            "type": "string",
            "title": "Actor Type"
          },
          "actor_name": {
            "type": "string",
            "title": "Actor Name"
          },
          "terminal_type": {
            "type": "string",
            "title": "Terminal Type"
          },
          "num_sessions": {
            "type": "number",
            "title": "Sessions"
          },
          "lines_added": {
            "type": "number",
            "title": "Lines Added"
          },
          "lines_removed": {
            "type": "number",
            "title": "Lines Removed"
          },
          "commits": {
            "type": "number",
            "title": "Commits by Claude Code"
          },
          "pull_requests": {
            "type": "number",
            "title": "Pull Requests by Claude Code"
          },
          "edit_tool_accepted": {
            "type": "number",
            "title": "Edit Tool Accepted"
          },
          "edit_tool_rejected": {
            "type": "number",
            "title": "Edit Tool Rejected"
          },
          "write_tool_accepted": {
            "type": "number",
            "title": "Write Tool Accepted"
          },
          "write_tool_rejected": {
            "type": "number",
            "title": "Write Tool Rejected"
          },
          "model_breakdown": {
            "type": "array",
            "title": "Model Breakdown"
          }
        },
        "required": ["record_date", "organization_id"]
      },
      "mirrorProperties": {},
      "calculationProperties": {
        "total_lines_changed": {
          "title": "Total Lines Changed",
          "calculation": ".properties.lines_added + .properties.lines_removed",
          "type": "number"
        },
        "edit_acceptance_rate": {
          "title": "Edit Acceptance Rate",
          "calculation": "if (.properties.edit_tool_accepted + .properties.edit_tool_rejected) > 0 then (.properties.edit_tool_accepted / (.properties.edit_tool_accepted + .properties.edit_tool_rejected)) * 100 else 0 end",
          "type": "number"
        }
      },
      "aggregationProperties": {},
      "relations": {}
    }

  4. Click Save to save the blueprint.

Configuration​

After installation, define which endpoints to sync in your integration configuration. Each resource maps an API endpoint to Port entities using JQ expressions to transform the data.

Key mapping components:

  • kind: The API endpoint path (combined with your base URL).
  • selector.query: JQ filter to include/exclude entities (use 'true' to sync all).
  • selector.data_path: JQ expression pointing to the array of items in the response.
  • port.entity.mappings: How to map API fields to Port entity properties.

For more details on how the Ocean Custom Integration works, see the How it works section in the custom integration overview.

To configure the mappings:

  1. Go to your data sources page.

  2. Find your Claude AI integration in the list.

  3. Click on the integration to open the mapping editor.

  4. Add the resource mapping configurations below.

    Organization usage metrics mapping (click to expand)

    This endpoint provides detailed usage metrics including token consumption:

    resources:
      - kind: /v1/organizations/usage_report/messages
        selector:
          query: 'true'
          method: GET
          headers:
            anthropic-version: "2023-06-01"
          query_params:
            starting_at: "2025-01-01T00:00:00Z"
            bucket_width: "1d"
          data_path: .data[]
        port:
          entity:
            mappings:
              identifier: .starting_at[:10] + "-usage"
              title: '"Claude Usage - " + .starting_at[:10]'
              blueprint: '"claude_usage_record"'
              properties:
                record_date: .starting_at
                uncached_input_tokens: (.results[0].uncached_input_tokens // 0)
                output_tokens: (.results[0].output_tokens // 0)
                cache_read_input_tokens: (.results[0].cache_read_input_tokens // 0)
                cache_creation_5m_tokens: (.results[0].cache_creation.ephemeral_5m_input_tokens // 0)
                cache_creation_1h_tokens: (.results[0].cache_creation.ephemeral_1h_input_tokens // 0)
                web_search_requests: (.results[0].server_tool_use.web_search_requests // 0)
    Response structure

    The API returns data in daily buckets. Each bucket has starting_at, ending_at, and a results[] array. Days with no usage will have an empty results array.

    Date range: Replace starting_at with your desired start date. The API requires this parameter and returns a maximum of 31 days per request with daily buckets.

    Pagination: For date ranges exceeding 31 days, use the next_page token from the response to fetch additional data.

    Cost report mapping (click to expand)

    This endpoint provides cost data for monitoring organizational spending:

    resources:
      - kind: /v1/organizations/cost_report
        selector:
          query: 'true'
          method: GET
          headers:
            anthropic-version: "2023-06-01"
          query_params:
            starting_at: "2025-01-01T00:00:00Z"
            bucket_width: "1d"
          data_path: .data[]
        port:
          entity:
            mappings:
              identifier: .starting_at[:10] + "-cost"
              title: '"Claude Cost - " + .starting_at[:10]'
              blueprint: '"claude_cost_record"'
              properties:
                record_date: .starting_at
                amount: ((.results[0].amount // "0") | tonumber)
                currency: (.results[0].currency // "USD")
    Cost data format

    The API returns cost amounts as strings (e.g., "0.057"). The mapping converts this to a number using tonumber.

    Workspace-level usage metrics mapping (click to expand)

    Track usage metrics at the workspace level by grouping the usage report by workspace_id:

    resources:
      - kind: /v1/organizations/usage_report/messages
        selector:
          query: 'true'
          method: GET
          headers:
            anthropic-version: "2023-06-01"
          query_params:
            starting_at: "2025-01-01T00:00:00Z"
            bucket_width: "1d"
            group_by[]: "workspace_id"
          data_path: '.data[] | select(.results | length > 0) | . as $bucket | .results[] | . + {bucket_date: $bucket.starting_at}'
        port:
          entity:
            mappings:
              identifier: (.workspace_id // "default") + "-" + .bucket_date[:10]
              title: (.workspace_id // "default") + " - " + .bucket_date[:10]
              blueprint: '"claude_workspace_usage"'
              properties:
                record_date: .bucket_date
                workspace_id: (.workspace_id // "default")
                uncached_input_tokens: (.uncached_input_tokens // 0)
                output_tokens: (.output_tokens // 0)
                cache_read_input_tokens: (.cache_read_input_tokens // 0)
                cache_creation_5m_tokens: (.cache_creation.ephemeral_5m_input_tokens // 0)
                cache_creation_1h_tokens: (.cache_creation.ephemeral_1h_input_tokens // 0)
                web_search_requests: (.server_tool_use.web_search_requests // 0)
    Workspace grouping

    When using group_by[]=workspace_id, results are broken down per workspace within each daily bucket. The data_path uses JQ to:

    • Filter out buckets with empty results using select(.results | length > 0).

    • Store the bucket in a variable $bucket to preserve the date.

    • Flatten results and inject bucket_date from the parent bucket.

    Usage not associated with a workspace will have workspace_id: null.

    Model-level usage metrics mapping (click to expand)

    Track usage metrics at the model level by grouping the usage report by model:

    resources:
      - kind: /v1/organizations/usage_report/messages
        selector:
          query: 'true'
          method: GET
          headers:
            anthropic-version: "2023-06-01"
          query_params:
            starting_at: "2025-01-01T00:00:00Z"
            bucket_width: "1d"
            group_by[]: "model"
          data_path: '.data[] | select(.results | length > 0) | . as $bucket | .results[] | . + {bucket_date: $bucket.starting_at}'
        port:
          entity:
            mappings:
              identifier: .model + "-" + .bucket_date[:10]
              title: .model + " - " + .bucket_date[:10]
              blueprint: '"claude_model_usage"'
              properties:
                record_date: .bucket_date
                model: .model
                uncached_input_tokens: (.uncached_input_tokens // 0)
                output_tokens: (.output_tokens // 0)
                cache_read_input_tokens: (.cache_read_input_tokens // 0)
                cache_creation_5m_tokens: (.cache_creation.ephemeral_5m_input_tokens // 0)
                cache_creation_1h_tokens: (.cache_creation.ephemeral_1h_input_tokens // 0)
                web_search_requests: (.server_tool_use.web_search_requests // 0)
    Model grouping

    When using group_by[]=model, results show token usage per model (e.g., claude-opus-4-5-20251101, claude-haiku-4-5-20251001). The data_path uses JQ to:

    • Filter out buckets with empty results using select(.results | length > 0).
    • Store the bucket in a variable $bucket to preserve the date.
    • Flatten results and inject bucket_date from the parent bucket.
    Claude Code analytics mapping (click to expand)

    Track Claude Code usage metrics including sessions, lines of code, commits, and pull requests:

    Requires Claude Code access

    This endpoint requires access to Claude Code. You'll receive an error if your organization doesn't have Claude Code enabled.

    resources:
      - kind: /v1/organizations/usage_report/claude_code
        selector:
          query: 'true'
          method: GET
          headers:
            anthropic-version: "2023-06-01"
          query_params:
            starting_at: "2025-01-01"
          data_path: .data[]
        port:
          entity:
            mappings:
              identifier: .organization_id + "-" + (.actor.api_key_name // .actor.email // "unknown") + "-" + .date[:10]
              title: (.actor.api_key_name // .actor.email // "unknown") + " - " + .date[:10]
              blueprint: '"claude_code_analytics"'
              properties:
                record_date: .date
                organization_id: .organization_id
                actor_type: .actor.type
                actor_name: (.actor.api_key_name // .actor.email // "unknown")
                terminal_type: .terminal_type
                num_sessions: (.core_metrics.num_sessions // 0)
                lines_added: (.core_metrics.lines_of_code.added // 0)
                lines_removed: (.core_metrics.lines_of_code.removed // 0)
                commits: (.core_metrics.commits_by_claude_code // 0)
                pull_requests: (.core_metrics.pull_requests_by_claude_code // 0)
                edit_tool_accepted: (.tool_actions.edit_tool.accepted // 0)
                edit_tool_rejected: (.tool_actions.edit_tool.rejected // 0)
                write_tool_accepted: (.tool_actions.write_tool.accepted // 0)
                write_tool_rejected: (.tool_actions.write_tool.rejected // 0)
                model_breakdown: .model_breakdown
    Claude Code response structure

    The Claude Code endpoint returns per-actor records. Each record includes:

    • Actor: Either a user (with email) or an API key (with name).

    • Core metrics: Sessions, lines of code, commits, and pull requests.

    • Tool actions: Acceptance/rejection counts for edit and write tools.

    • Model breakdown: Token usage and estimated cost per model.

    Date format: This endpoint uses YYYY-MM-DD format (not RFC 3339).

  5. Click Save to save the mapping.

Customization​

If you want to customize your setup or test different API endpoints before committing to a configuration, use the interactive builder.

The interactive builder helps you:

  1. Test your Claude API endpoints with live data.
  2. Automatically detect the data structure and field types.
  3. Generate blueprints and resource mappings tailored to your preferences.
  4. Get installation commands with your configuration pre-filled.

Simply provide your Anthropic API details, and the builder will generate everything you need to install and create the integration in Port.

Last updated on
